Batteries

Quality you can trust!

The performance of power-optimized solutions depends on reliable battery technologies and suppliers with proven implementations. The following reference batteries are recommended for use in Mobile IoT devices.

EVE logo EVE
CR2/3AL 3V Primary lithium-manganese dioxide (Li-MnO₂) spiral cell
CR2/3AL product image
Nominal Voltage: 3.00 V
Nominal Capacity: 4.80 Wh
Nominal Capacity: 1.60 Ah
Yearly Self-discharge: 2.00 %
Discharge Current: 1000.00 mA
Temperature Range: -40°C to 70°C
More Info Purchase
CR17450 3V Primary lithium-manganese dioxide (Li-MnO₂) spiral cell
CR17450 product image
Nominal Voltage: 3.00 V
Nominal Capacity: 7.80 Wh
Nominal Capacity: 3.00 Ah
Yearly Self-discharge: 2.00 %
Discharge Current: 1000.00 mA
Temperature Range: -40°C to 85°C
More Info Purchase
CR17450L 3V Primary lithium-manganese dioxide (Li-MnO₂) spiral cell
CR17450L product image
Nominal Voltage: 3.00 V
Nominal Capacity: 7.20 Wh
Nominal Capacity: 3.00 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 1000.00 mA
Temperature Range: 70°C to -40°C
More Info Purchase
ER14250 3.6V Primary lithium-thionyl chloride (Li-SOCl₂) bobbin cell
ER14250 product image
Nominal Voltage: 3.60 V
Nominal Capacity: 4.32 Wh
Nominal Capacity: 1.20 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 35.00 mA
Temperature Range: -55°C to 85°C
More Info Purchase
ER17505 3.6V Primary lithium-thionyl chloride (Li-SOCl₂) bobbin cell
Nominal Voltage: 3.60 V
Nominal Capacity: 12.96 Wh
Nominal Capacity: 3.60 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 100.00 mA
Temperature Range: -55°C to 85°C
More Info Purchase
ER26500C 3.6V Primary lithium-thionyl chloride (Li-SOCl₂) bobbin cell
ER26500C product image
Nominal Voltage: 3.60 V
Nominal Capacity: 30.60 Wh
Nominal Capacity: 8.50 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 150.00 mA
Temperature Range: -55°C to 85°C
More Info Purchase
ER34615C 3.6V Primary lithium-thionyl chloride (Li-SOCl₂) bobbin cell
ER34615C product image
Nominal Voltage: 3.60 V
Nominal Capacity: 68.40 Wh
Nominal Capacity: 19.00 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 100.00 mA
Temperature Range: -55°C to 85°C
More Info Purchase
Murata logo Murata
CR2450R 3V Rechargable lithium-manganese dioxide (Li-MnO₂) coin cell
CR2450R product image
Nominal Voltage: 3.00 V
Nominal Capacity: 1.50 Wh
Nominal Capacity: 0.50 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 50.00 mA
Temperature Range: -30°C to 70°C
More Info Purchase
CR2477X 3V Rechargable lithium-manganese dioxide (Li-MnO₂) coin cell
CR2477X product image
Nominal Voltage: 3.00 V
Nominal Capacity: 3.00 Wh
Nominal Capacity: 1.00 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 30.00 mA
Temperature Range: -40°C to 85°C
More Info Purchase
CR3677X 3V Rechargable lithium-manganese dioxide (Li-MnO₂) coin cell
CR3677X product image
Nominal Voltage: 3.00 V
Nominal Capacity: 6.00 Wh
Nominal Capacity: 2.00 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 80.00 mA
Temperature Range: -40°C to 85°C
More Info Purchase
Panasonic logo Panasonic
CR-2U 3V Primary lithium-manganese dioxide (Li-MnO₂) spiral cell
Nominal Voltage: 3.00 V
Nominal Capacity: 3.00 Wh
Nominal Capacity: 1.00 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 1000.00 mA
Temperature Range: -40°C to 85°C
More Info Purchase
CR-2Z 3V Primary lithium-manganese dioxide (Li-MnO₂) spiral cell
Nominal Voltage: 3.00 V
Nominal Capacity: 3.00 Wh
Nominal Capacity: 1.00 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 1000.00 mA
Temperature Range: -40°C to 85°C
More Info Purchase
CR-2/3AZ 3V Primary lithium-manganese dioxide (Li-MnO₂) spiral cell
Nominal Voltage: 3.00 V
Nominal Capacity: 8.10 Wh
Nominal Capacity: 1.60 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 2000.00 mA
Temperature Range: -40°C to 85°C
More Info Purchase
CR-AAU 3V Primary lithium-manganese dioxide (Li-MnO₂) spiral cell
Nominal Voltage: 3.00 V
Nominal Capacity: 5.40 Wh
Nominal Capacity: 1.80 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 2000.00 mA
Temperature Range: -40°C to 85°C
More Info Purchase
CR-AG 3V Primary lithium-manganese dioxide (Li-MnO₂) spiral cell
Nominal Voltage: 3.00 V
Nominal Capacity: 7.20 Wh
Nominal Capacity: 2.40 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 2000.00 mA
Temperature Range: -40°C to 85°C
More Info Purchase
CR-AGZ 3V Primary lithium-manganese dioxide (Li-MnO₂) spiral cell
Nominal Voltage: 3.00 V
Nominal Capacity: 8.10 Wh
Nominal Capacity: 2.70 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 2000.00 mA
Temperature Range: -40°C to 85°C
More Info Purchase
CR-LAZ 3V Primary lithium-manganese dioxide (Li-MnO₂) spiral cell
Nominal Voltage: 3.00 V
Nominal Capacity: 9.00 Wh
Nominal Capacity: 3.00 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 2000.00 mA
Temperature Range: -40°C to 85°C
More Info Purchase
Saft logo Saft
LM 17500 3V Primary lithium-manganese dioxide (Li-MnO₂) spiral cell
LM 17500 product image
Nominal Voltage: 3.00 V
Nominal Capacity: 8.70 Wh
Nominal Capacity: 3.00 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 1500.00 mA
Temperature Range: -20°C to 65°C
More Info Purchase
LM 26500 3V Primary lithium manganese dioxide (Li-MnO₂) C-size spiral cell
LM 26500 product image
Nominal Voltage: 3.00 V
Nominal Capacity: 20.90 Wh
Nominal Capacity: 7.40 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 2000.00 mA
Temperature Range: -20°C to 65°C
More Info Purchase
LS 17500 3.6V Primary lithium-thionyl chloride (Li-SOCl₂) bobbin cell
LS 17500 product image
Nominal Voltage: 3.60 V
Nominal Capacity: 12.96 Wh
Nominal Capacity: 3.60 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 100.00 mA
Temperature Range: -40°C to 70°C
More Info Purchase
LS 26500 3.6V Primary lithium-thionyl chloride (Li-SOCl₂) bobbin cell
LS 26500 product image
Nominal Voltage: 3.60 V
Nominal Capacity: 27.72 Wh
Nominal Capacity: 7.70 Ah
Yearly Self-discharge: 1.00 %
Discharge Current: 150.00 mA
Temperature Range: -60°C to 85°C
More Info Purchase
LSH 20 3.6V Primary lithium-thionyl chloride (Li-SOCl₂) high power D-size spiral cell
LSH 20 product image
Nominal Voltage: 3.60 V
Nominal Capacity: 46.80 Wh
Nominal Capacity: 13.00 Ah
Yearly Self-discharge: 3.00 %
Discharge Current: 1800.00 mA
Temperature Range: -40°C to 70°C
More Info Purchase
